Polypropylene laboratory fume hood CF1200P
Polypropylene laboratory fume hood CF1200P
Specification:
1.Outer
dimension（L*W*H）: 1200*850*2350mm
2.Max
door open：820mm（vertically adjustable）
3.Working
board material：White
PP,thickness 8MM, bending designed to avoid spilling over.options for solid physiochemical board or epoxy
resin or ceramic.
4.Power: AC220V,50~60HZ
5.exhaust
flux at air speed 0.5m/s:23.4CMM/840CFM
6.Operation panel：Transparent tempered glass, thickness 5MM
7.Gas collecting hood：Conical necking type
8. Standard parts：All cover fluorescent 30Wx1，Power socket AC220V/10A X 4pcs， Power switch board，Remote control water valves for pure water and pipe water，PP sink*1pcs
Options
for other parts: Cups,sinks,air
cocks, water cocks, air blowers, power sockets,explosion-proof lighting,Venturi valve control, Butterfly
valve control, converter
control,touch pad, Surface
wind speed detection, sound
and light alarm, etc.
Feature:
1.Fume Hood (fume cupboard & fume cabinet): main structure made of high quality PP board, perfect for resisting corrosion and heat.
2.Sash: The full view vertical raising sash is manufactured of laminated safety glass with the sash set into an extruded, low turbulence PVC track that delivers smooth operation and steady sash positioning.
3.Polypropylene laboratory fume hood CF1200P
Worktop: White PP,thickness 8MM, bending designed to avoid spilling over.options for solid physiochemical board or epoxy resin or ceramic.
4.Lighting: 30W fluorescent lamp and switch.
5.Power: AC220V,50~60HZ
6.Exhaust system: The exhaust collar connects the fume hood to the exhaust duct.
7.Polypropylene laboratory fume hood CF1200P
Exterior Dimensions: 1200*850*2350mm
8.Air Volume: 23.4CMM/840CFM
Cabinet structure:
1、 Upper part： Polypropylene material for all weather Condition.
2、Working board： Special design for comfortable working,
3、 Bottom part：Tube structure storage cabinet. Strong loading capacity.
4、 Movable door：5mm tempered glass.Hanging type cable connection. Good for sight checking and manual moving.
5、Power supply device：switch：visible LCD control panel; Water proof cover for power socket
